Recently, while looking at integrating Braze into an application, I came across a field in BrazeFileUtils called REMOTE_SCHEMES and I was curious to see what the values were that Braze considered for REMOTE_SCHEMES.

Looking at the docs, there was no reference to what the schemes were, so I thought I'd do a little digging myself to see if I could infer what the value was for this field.


The first step of the process was to create a new Android application that include the dependency I wanted to look at, namely BrazeFileUtils. This can be accomplished by bringing the Braze SDK into our application via

    implementation 'com.appboy:android-sdk-ui:24.3.0'
    implementation 'com.appboy:android-sdk-location:24.3.0'

After that, I generated a debuggable apk via ./gradlew :app:assembleDebug. Once I had a debug APK in hand, the next tool I brought in to help was Apktool, a tool for reverse engineering Android apk files.


  1. By following the instructions on the site, and downloading the latest Apktool JAR file, we are ready to decompile the debug APK we generated earlier. I decompiled the apk via java -jar apktool.jar d app-debug.apk where apktool.jar is the jar downloaded from the Apktool website and app-debug.apk is the debug APK generated from the previous step.

  2. After decompilng via Apktool, we are ultimately left with .smali files, the assembly language used by the Android Dalvik Virtual Machine; usually created by decompiling. We are getting close though! If we open up the new app-debug folder created from Apktool, we can look inside /smali/com/braze/support/BrazeFileUtils.smali and see the field we want! Unfortunately, we don't see the values for it yet.

  1. The next step is to use a Dex (Smali) to Java decompiler to get the code in a format a little more digestible by a human. For this, we will use jadx. Following the instructions in the readme, and installing jadx via brew (brew install jadx), we are ready for the next step.

  2. After installing jadx, we can finally get the Java code from the .smali files generated earlier via jadx -d out app-debug/smali/com/braze/support/BrazeFileUtils.smali. Usage is from the docs on the site as follows:

     jadx[-gui] [options] <input files> (.apk, .dex, .jar, .class, .smali, .zip, .aar, .arsc, .aab)
       -d, --output-dir                    - output directory

After opening up the Java file, we can finally see what the remote schemes are!

In conclusion, we utilized Apktool and jadx to reverse engineer source from a debug apk. This can be useful when a 3rd party tool that you have to utilize doesn't expose certain things about their SDK.
